PRELIMINARY SPECIFICATIONS - SUBJECT TO VERIFICATION:
Bending capacities: 4' x 14 ga. mild steel
Tonnage capacity: 17 tons
Overall length of bed & ram: 48"
Distance between housings: 36"
Stroke: 2"
Ram adjustment: 2"
Shut height S.D.A.U.: 9"
Throat depth: 6-1/2"
Width of bed: 1-1/2"
Floor to top of bed: 32-3/4"
S.P.M. approx.: 17
EQUIPPED WITH:
18" front operated manual back gauge via hand wheel with vertical
adjustment
3" high die rail
Electric foot switch
Dual palm buttons for run with emergency stop button
Pushbuttons for start - stop
Selector switch for inch - auto -return
Key selector switch for hand - foot
Sectional ram die clamps
Manual ram adjustment with position indicators
Hydraulic pump, driven by 3 HP 1140 RPM 208/230/460/3/60 motor
DIMENSIONS (APPROXIMATE) L-R x F-B x H 56" X 55" X 82" HIGH
WEIGHT (APPROXIMATE) 2200 LBS.
