Capacity: 250 Ton
Stroke: 0 - 12"
Speed - Closing: 126 IPM
Pressing: 48 IPM
Return: 294 IPM
Daylight: 24"
Closed Height: 12"
Bed Area: 58" LR x 34" FB
Ram Area: 35" LR x 27" FB
OOpen Thru Frame: 23"
Working Height: 36" Floor to Bed
Below Floor Design: 7" Projection below Floor Grad
Approx Size: 70" LR X 120" FB X 168"H
Weight Approx: 60,500 Lbs
Equipped With:
Vickers Hydraulics
Pedestal Mounted Operator Controls
Pressure Controls
Selector Switch for Jog - Single Stroke
Tee Slotted Bed
Hydraulic Knockout
Hand Wheels for Stroke Adjustment Setting - Ram Positioning
Manually Adjustable Limit Controls for Depth Stop & Speed Control
Rigid Steel Frame Welded Construction
Machine Taken from Service in Excellent Condition - New Ram Seal in 2011 **
** Preliminary Specifications subject to verification **
