Machine Beam On 23000 hours.
Trumpf Introduces Trumatic L2530
Trumpf Inc. has introduced the Trumatic L2530 flatbed laser that allows for thick and thin sheet metal working in a compact machine which can be easily moved and integrated into an existing shop floor operation.
The L2530 laser cutting system takes the inherent flexibility of a laser one step further and makes the machine structure itself equally versatile by allowing the machine to be configured to match the user's manufacturing requirements and complement the shop floor environment.
Designed for ergonomic work processes, the L2530 is fed "longways on." The machine front may be opened over its entire width to facilitate loading and unloading parallel to production and the pallet changer is accessible from three sides. This not only provides greater accessibility to parts, but is among the many design features of the machine. In addition, the machine body consists of a single welded construction; it is designed with a minimal space requirement; it is simple to operate; and has newly integrated features that meet high safety and environmental standards. Despite its small footprint, the L2530 accommodates a full 4 x 8-foot working range.
Ideal for cutting a variety of thick and thin materials, the L2530 can be equipped with a TLF turbo lasers with 3000 watts to suit a myriad of applications.
In addition to its flexibility, the L2530 is designed for reliability and low maintenance. It uses flying optics and is designed for operations requiring superior cutting quality, flexibility and the economical production of Just-In-Time sheet metal deliveries.
Specifications:
Watts 3000
Sheet Capacity 4' x 8'
Travels Y Axis 100"
X Axis 50"
Z Axis 4.5"
Number of tables 2 Auto Pallet Shuttle
Rapid Traverse Rate 3346 IPM
