Max. slide effort at the distance of 27 mm to the lower dead point: 5000 kN
Slide effort at the distance of 160 mm to the lower dead point: 250 kN
Number of single strokes per minute: 12
Slide stroke: 400 mm
Slide adjustment: 220 mm
Ejector stroke: 180 mm
Thickness of plate with slots for fastening: 175 mm
Inner height between plate with slots and pusher (stroke down, adjustment up): 675 mm
Clearance between columns: 1000 mm
Table area: 1000x1400 mm
Table opening: 710x710 mm
Pusher area: 800x1120 mm
Table cushion:
-Max. stroke: 160 mm
-Stroke adjustment: 160 mm
-Max. retention effort: 800 kN
-Max. ejection effort: 125 kN
Main motor power: 41 kW; 1320 rpm
Power of pusher motor: 3,5 kW; 1420 rpm
Number of revs of flywheel shaft: 630 rpm
Press weight: 43 tons
