Intended for production of a variety of parts from sheets using various cold stamping operations: blanking, punching, non-deep drawing, bending, etc. The press can perform flash trimming of billets, in a hot or cold state, produced using the hot-forging equipment.
Specifications:
Nominal force: 1000 tons
Not reaching of lower dead point by the slide: 8 mm
Slide stroke: 500 mm
Number of continuous strokes per minute: 20
Max. number of single strokes per minute: 15
Closed height: 680 mm
Adjustment of closed height: 200 mm
Slide dimensions:
-Left-to-right: 1250 mm
-Front-to-back: 1250 mm
Bolster plate dimensions:
-Left-to-right: 1250 mm
-Front-to-back: 1250 mm
Main drive electric motor power: 75 kW
