Specifications:
LENGTH OF CUT ------------------------- 122"
CAPACITY OF CUT:
(50,000 PSI MILD STEEL) --------------- 1/2"
LENGTH OF SQUARING ARM FROM BED ------- 14"
RANGE OF BACKGAUGE: MINIMUM ----------- 1"
MAXIMUM ----------- 39"
MOTOR --------------------------------- 30 HP
ELECTRICS ----------------------------- 240-480 VAC/3 PH/60 HZ
HYDRAULIC OIL CAPACITY ---------------- 80 GALLONS
HYDRAULIC PRESSURE AT HOLD DOWNS ------ 1400 PSI/EACH
HYDRAULIC SYSTEM PRESSURE ------------- 3800 PSI
WEIGHT -------------------------------- 21,000 LBS
DIMENSIONS ---------------------------- 14' L X 7' W X 8' H
EQUIPPED WITH:
- POWER RAKE-ANGEL ADJUSTMENT
- MANUAL BLADE CLEARANCE ADJUSTMENT
- 6' SQUARING ARM
- (2) SHEET SUPPORTS
