Technical Details:
X - travel: 630 mm
Y - travel: 500 mm
Z - travel: 560 mm
angular adjustment of indexing table: 360 x 1°
dimensions of the machine: 3,8 x 3,9 x 3,0 m
feed stepless: 1 - 24.000 mm/min
no. of tools in the magazine: 48
numbers of pallets: 2
pallet table size: 400 x 500 mm
rapid travel X / Y / Z: 24.000 mm/min
rapid traverse feeds rotary table: 30 1/min
spindle motor: 143 Nm
spindle taper: SK 40
spindle turning speed: 45 - 8.000 1/min
table load: 400 daN
voltage: 400 V / 50(60) Hz
weight of the machine: 7,5 t
Specifications:
Features • Controltyp: uni-Pro90 • Motortype: DIGI-DRIVE • Cooling system: Knoll • Chip conveyor: Knoll • Colour: white Available Optionens • mechanical Retrofit Good condition - can be seen under power !
