High-speed hydraulic riveting machine is generally applied in heavy truck, bus, car, motorcycle, train, agricultural vehicle, mine-vehicle, aeroplane, bridge structure etc.

Hydraulic Riveting Machine:
High-speed hydraulic riveting machine is generally applied in heavy truck, bus, car, motorcycle, train, agricultural vehicle, mine-vehicle, bridge structure etc.

Products performance:
The device uses transmission and control, machine output full hydraulic pressure, you can direct cold riveting, riveting mention the high quality. So compared with conventional pneumatic riveting, with the industrial environment is good, no noise, flexible operation, lightweight, low labor intensity, riveting speed, high production efficiency.

Main purpose:
1. heavy vehicles, buses, light vehicles, agricultural vehicles and other frame manufacturing.
2. riveting aspects gondola railway vehicles, wagons, tankers and other side of the frame, the core plate, the plate seat, the seat and the side pillar side impact beams and the like.
3. Assembling steel bridge.
4. tub caulking.
Mounted corresponding device can also be punching, crimping, printing and molding and other operations.

Features of Hydraulic Riveting Machine:
1. The low noise
2. The low labor intensity
3. The high riveting speed about 1/3(s)
4. The high riveting force is used in cold or hot riveting
5. The equal riveting force and high quality which can partly correct vehicles’ frame.

Parameters of Hydraulic Riveting Machine:
1.Model: T92Y-50
2.Riveting force: 500 (KN)
3.System pressure force: 7.5 (mpa)
4.Riveting rate: 15-20 (min-1)
5.Max riveting diameter (cold) : 16
6.Max riveting diameter (heat) : 24-28
7.Pump displacement: 56 (ml/r)
8.Motor power: 11 (kw)
9.Oil tank volume: 650 (L)
10.Oil pipe joint: M36*2 (mm*mm)
