Technical Details:
gear width: 16 mm
max. wheel diameter: 150(aussen) mm
Machine colour: grau
max. module: max. 3
stroke: 0-20 mm
total power requirement: 15 kW
weight of the machine: ca. 6,5 t
Additional information: max. wheel diameter 150(external) mm; Gear width, max. 16 mm; Internal gears, max. diameter 60 + Schneiderad-/-E mm; Internal gears, max. workpiece diameter, approx ca. 280 mm; Adjustment of stroke 0 - 70 mm; Table size 250 mm; Table bore 100 mm; Total electrical load, approx. ca. 29 kVA.

-
