cutting diameter: mm
saw band length: 4335 mm
cutting width: mm
dimensions of saw-blade: 4335 x 1,1 x 34 mm
total power requirement: 50 Hz, 380 V
weight of the machine ca.: 800 kg
dimensions of the machine ca.: 2100 x 800 x 1300 mm
Specifications:
sectional area
around 0 ° flat flat 45 ° flat 60 °
90 ° 320 510 x 250 470 x 320 320 x 320
45 ° R 320 360 x 180 310 x 320 310 x 310
45 ° L 320 360 x 180 270 x 320 310 x 310
30 ° R 220 220 x 240 180 x 320 220 x 220
30 ° L 170 240 x 170 240 x 170 170 x 170
