Cutting capacity round / square 90° 220 mm / 220 x 220 mm
Cutting capacity flat 90° 265 x 150 mm
Cutting capacity round / square 45° R 175 mm / 160 x 160 mm
Cutting capacity flat 45° R 170 x 135 mm
Cutting capacity round / square 45° L 155 mm / 135 x 135 mm
Cutting capacity round 45° L 175 x 65 mm
Cutting capacity round / square 60° R 110 mm / 80 x 80 mm
Cutting capacity flat 60° R 110 x 80 mm
Working height 900 mm
Bansaw blade dimensions 2600 x 27 x 0,9 mm
Cutting speeds 40 / 80 m/min
Coolant pump 100% 90 W
Motor power output 100% 1,1 kW
Motor power input 40% 1,5 kW
Voltage 400 V
Machine dimensions (W x D x H) 1400x660x1400 mm
Weight approx. 250 kg

-
