cutting range:

- 90° - 650 x 400 mm

- 90° - round - 400 mm

- 45° - 300 x 300 mm

- 16.5° - 600 x 300 mm or 450 x 400 mm

mitre adjustment hydraulically 45 / 15°

stageless adjustment of cutting pressure

saw band dimensions 38 x 1.4 x 5,040 mm

band speeds 5 steps 27 / 40 / 50 / 60 / 70 m/min

saw band cleaning brush/scraper

hydraulic clamping of material

hydraulic bundle clamping device

manual material feed

working height approx. 720 mm

cooling liquid device

electrical data 380 V / 4.5 KW

space required length - 2,660 x depth - 1,600 x height -
2,450 mm

weight approx. 2,500 kg

list of spare parts available

-
