Structure
• Triple precision ground wheels and widened double track
• Extra wide-frame saw arm with self-contained hydraulic system
• Extra heavy-duty worktable for plates of large weights
Blade Drive
• Driven by a massive 7.5 hp motor through power efficient planetary gearbox
• Planetary gearbox guaranteeing high transmission efficiency
• Infinitely variable blade speed controlled by world-brand inverter
Blade Guidance & Lubrication System
• Hydraulic Tungsten Carbide Blade Guides with bearing guides
• Blade deviation detector
• Hydraulically powered guide arm controlled directly from control panel
• Automatic hydraulic blade tensioning device
• Integral coolant system
• Powered chip removal system
Control & Automation
• LCD Screen indicating feed rate, cutting rate, blade speed and cutting time
• Work length setting
• Error message feedback
• Automatic shutoff at end of last cut
• Slow Entry and Exit Modes (SEEM)
• Servo motor controlled cutting pressure
• Automatic torque adjustment
Material Feeding & Clamping
• AC Servo Motor coupled with planetary gearbox enabling high torque and low speed capability
• Smooth, pulse free feeding from 2 mm/min to 2000 mm/min
• Laser alignment beam light for easy measurement (optional)
Safety
• Interlock design in electrical and hydraulic system
• Conduits protection measure
• "Alert Orange" safety measure
Standard Accessories
• Additional flushing hose
• Bi-metal saw blade
• Tool box, leveling pads, and an additional wire brush
• Operation & parts manual
