SPECIFICATIONS:
Blade diameter 16" (400mm)
Cut capacity--90 degrees 4" x 7"
--45 degrees 4" x 5"
Saw blade mitre 90 to 45 degrees (left or right)
Saw blade compound 90 to 45 degrees
Main motor 3 HP (2.2KW)
Motor speed 2800 rpm
Electrics 230/460/3/60
Dimensions (L x W x H) 34" x 28" x 69"
EQUIPPED WITH:
Semi-automatic, Two (2) horizontal pneumatic clamps, Spray mist system
Head rotate: mitre and/or compound angles, Push button cycle activation
Hydro pneumatic feed system, 16' long entry and exit conveyor tables
Laser beam system for acurate and simplified cutting
