Machine Capacity:
Round: 4.75"
Square: 4.375"
Extrusions: 7.75" x 4.0"
Saw Blade: Carbide tipped or high speed steel
350mm diameter
Electrics: 8.7/11.5 HP, Wired 240V, 3 Phase
(17 amp)
Blade Speed: 2 speed - 1700/3400 RPM
Air Pressure Required: 100 PSi
Dimensions (approx.): 4' x 6' x 8'
Weight (approx.): 2,200 lbs
Equipped with (must be verified by buyer):
Chip Collector
90"l x 12"w Steel Topped Material Support Table
60" Rubber Coated Roller Conveyor
Vertical Bundle Clamp
Variable Vise Pressure
Allen Bradley SLC500 PLC
Heavy Duty Saw Head Double Shaft Design Travels On A Pivot Center Of Cast
Iron Construction
Hydra-pneumatic System w/Infinitely Variable Feed Adjustment
Length Setting by Means of a Dial Setting w/Fine Tuning Wheel
Double Spray Mist Coolant System
Complete Saw Blade Guarding
Full Noise Reduction Enclosure
Enclosed Full Electric Over and Under Load Voltage Protection
Chip Ejection Chute for Effective Chip Removal From Sawing Area
