Description
Approximate Machine Age: 2001
Number of Axis 4
Maximum working diameter: .500"
Maximum machining length: 5.31"
Main Spindle Index: 1 degree Std
Max Spindle Tapping Dia. 7 MM
Max Rotary Tool Tapping M5 x 0.8
Spindle Speeds (Main) 100 - 12,000 rpm
Spindle Speeds (Sub) 100-7000 rpm
Spindle Motor 2.2 kw
Sub Spindle Index: 1 degree Std
# of tools: 6 turning (5) turning, (3) endworking
Main motor: 7.5hp
Coolant motor: 3HP
Tool Size tool (gang tool post): 3/8" x
Weight 2400 lbs ,
Dimensions 46" x 31" x 61"
Equipped With:
Iemca Boss 112 Magazine Type Bar Loader
Cincom 5a (Fanuc 18TC)
All available manuals
tooling/accessories associated with this machine
Condition: Excellent; one owner & single shift!
