Control: Mitsubishi Meldas-320LC
Cincom System II B
Simultaneous 5 Axis Control (Two Systems)
- Controlled axes: X1, X2, Z1, Z3, C1
Maximum Machining Diameter: 5/8"
Maximum Machining Length: 6.3"
Maximum Drilling Diameter: .315"
Maximum Threading Diameter (tap & die): .236"
Spindle Through Hole Diameter: .79"
Spindle Speed: 220 - 10000 rpm
Rotary Tools:
Maximum Drilling Diameter: .157"
Maximum Threading Diameter: M3
Spindle Speed: 320 - 6300 rpm
Back-work:
Maximum Chucking Diameter of Back-work Spindle: 5/8"
Maximum Back-work Length: 5.51"
Maximum Drilling Diameter: .236"
Maximum Threading Diameter: .157"
Back-work Spindle Speed: 200 - 5000 rpm
No. of Tools Installable: 20 (10 per turret)
No. of Rotary Tool Positions: 20
Tool Holders: 10 - 10mm
Tool Size: 1/2" x 1/2" x 2.36"
Main Spindle Motor Drive: 5 HP
Power Supply: 12 KVA
Required Floor Space: 56.3" x 77.95"
Weight (approx.): 6700 lbs
Equipped with (to be confirmed by buyer):
Tool Nose Radius Compensation
Milling Interpolation
(A&M is offering 2 Full running machines and 2 machines that we have not seen run but appear to be complete (3 machines located in san Jose, CA area and one is in CO)
$19500 EA for the completely running machines and $10,500 ea for the ones one under power
Tooling: New and Used Tooling Available .................................................... POR
Bar Feed Equipment: Hydraulic Gatling and Magazine loaders, Used & New... POR
Hi-Pressure coolant Systems, Mist Collectors, Tooling packages, etc............ POR
