Rough Material Guide Bushing, C-Axis Milling Capability on Main & Sub Spindle, B-Axis Live Tooling Programmable for Main & Sub Spindle, Fedek Sunny 542-37 Hydrodynamic 12 ft. Magazine Barfeed, Chip Conveyor, Three Color Tower Light, Miscellaneous Collets
Specifications:
Max Diameter Bar Capacity 1.65"
Max Machining Length 10.55"
Main Spindle Motor 7.4 HP
Main Spindle Speed 200 - 8000 RPM
Main Spindle Indexing .001 Degrees
Number of Tools: 21
Turning Tools 6
Live Tools 6
B-Axis Live Tools 3
Front End Working Tools (Fixed/Live) 2 / 2
Backworking Tools (Fixed/Live) 4 / 3
Rapid Traverse Rates (X, Y & Z) 709 IPM
Sub Spindle Motor 3 HP
Sub Spindle Speed 200 - 8000 RPM
Sub Spindle Bore 1.65"
Max Front Drilling 0.79"
Max Back Drilling/Tapping Dia. 0.63"
Machine Dimensions (L x W x H) 98" x 50" x 70"
Machine Weight 9012 lbs.
FEATURES:
MITSUBISHI CNC CONTROL
10.4" Color LCD
Rough Material Guide Bushing
C-Axis Milling Capability on Main & Sub Spindle
B-Axis Live Tooling Programmable for Main & Sub Spindle
Fedek Sunny 542-37 Hydrodynamic 12 ft. Magazine Barfeed
Chip Conveyor
Three Color Tower Light
Miscellaneous Collets
