STAR SA-12, 1/2", FANUC 18iTA,1999,3LIV/6OD/4ID/4BW,15DEG INDX, SUB-SPNDL, LNS BF

General Specifications per Brochure:

CNC Control: Fanuc 18iTA
Controllable Axes: X, Y, Z, Z2
Combinations of 6-OD tools, 3-power driven tools for cross drill/mill, front
& rear facing 4-spindle attachment for simultaneous drilling

Max. Turning Diameter: 1/2"
Max. Drilling Capacity:
Stationary Tool: 9/32"
Power-driven Attachment: 5/32"
Main Spindle Speed: 500 - 12,000 rpm
Motor: 2.2 KW/3.7 KW
Indexing: 15 degree
No. of Tools: 6 OD
4 ID
4 Backworking ID
2 Cross Mill/Drill
Sub-spindle: Turning Diameter: 1/2"
Speed: 500 - 8,000 rpm
Motor: .5 KW
Dimensions (approx.): 83"l x 31"w x 65"h
Weight (approx.): 3,740 lbs


Equipped With (to be confirmed by buyer):
LNS Tryton SST Gatling Style Loader

83" x 31" x 65"

3,740
