Capacity: 10'4" x 1/4" Mild Steel
Length of Knifes: 10' 4"
Distance Between Housings: 10' 4"
Rake Angle: 11/32"
Hydraulic Hold Downs: 8
Speeds Approx.: 207 IPM Down
276 IPM Up
Motor: 15 HP 1750 RPM 230/460/3
Over All Size Approx.: 144" L-R x 78" F-B x 90" H
Weight Approx.: 23,500 Lbs.
Equipped With:
36" Front Operated Power Back Gauge
w/Selector Switch For Fast In
Fast Out & Pushbutton For Slow In
Electric Foot Switch
Pushbuttons For Start - Stop
