Machine hours ca. (April 2012) 15.500 h
Laser hours ca. (April 2012) 6760 h
Working area X x Y x Z 3000 x 1500 x 115 mm
Lasertype CO2-Laser TruFlow 4000
Power 4000 W
CNC Sinumerik 840 D
Machine equipment
• Closed machine frame with integrated laser unit
• Laser unit CO2-Laser TruFlow 4000 stimulated high frequency, maintenance free radial turbo blower, reflecting telescope, cooling unit, logbook function
• Automatic pallet changer
• longitudinal conveyor for small parts/slug
• Drives: Maintenance-free 3-phase servo motors
• Additional highly dynamic Xp-axis
• Cutting head quick change device
• Cutting head with 5“-Lenses and 7,5“Lenses
• Laser cutting head with 3,75“ lens for high speed cutting
• Programmable cutting gas pressure adjustment
• ControllLine capacitive height control and process control
• Automatic focus adjustment FocusLine
• Laser power control
• Positions laser diode
• NitroLine high pressure cutting
• Fast turn around with SprintLine
• ContourLine for making small holes
• PlasmaLine
• Automatic sheet position detection
• Programmable power cycles
• Compressed air cutting
• PierceLine
• Microweld
• Spraying equipment for the safe handling sheet metal thicknes
• Automatic shutdown
• Work space lighting
• CNC Sinumerik 840 D
• Shopfloor programming
• Security: multi beam light barriers, completely encapsulated and purged beam delivery, monitoring system, multi-chamber extraction system and compact dust extractor, saftey cabin
• 3,5“-floppy drive
• TFT-color screen
Additional equipment
• TruFlow 4000 incl. NitroLine, jet ventilation with N2 and LensLine
• clamps (2 Stueck)
• Cross conveyor belt with the right container
• Right establishment machine
• Preparation LoadMaster
