Cutting force: 200 kN Matrialstärke: 4.5 mm Maximum sheet size: 1270 (X) x 1000 (Y) mm with 1 repositioning 2540 (X) x 1000 (Y) mm Max processing area: 1000x2000 mm punch accuracy: + / - 0 , 10 mm stroke length: 300 bpm 32 mm Nibbelhübe. Punching strokes: 180/min. (25 mm) Compression Engine: 3.7 kW turret: large turret 20 stations. 2 of them Amadex Small turret 18 stations, of which two Amadex turret rotation speed: 20 min.1 auto index rotation speed: 60 min.1 Maximum speed: 40 m / min. Power: 11 kVA (incl. CNC) Pressure Connection: 5.0 kg / CM interface: RS 232 C weight: 7500 kg
