numeric control: BOSCH Trumagraph CC 300
X movement: 2.000mm
Y movement: 1.000mm
X speed max.: 60m/min
Y speed max.: 45m/min
simultaneous speed max.: 75m/min
number of strokes max.: 500 1/min
workpiece weight max.: 100kg
plate thickness max.: 6,4mm
tools automatic changing: 10 p.
punch power max.: 250kN
punch diameter max.: 76mm
weight: 9.000kg
dimensions L*B*H: 5.430*6.225.2.100mm

equipment:
- Safety light barriers
- 10 off Loading Cartridges
- 360° tool rotation
- Part removal chute up to 300mm x 300mm
- Automatic tool change
- automatic repositioning
- Cutting suction system
- Tool length compensation
- Scrap box
- Good part box
- Programmable punching die lubrication with 2 tanks
- Programmable down-holder
- Graphic aided programming at the control with Bosch Trumagraph
- Owners manual
+ set of overhauled tooling amounting to 15.000,- € new price

-
