Description:
Job Title: 2535x1280 control: Siemens SINUMERIK 840 D mm Maximum thickness: 8 Max Werstückgewicht kg: 200 mm Max cutting diameter: 76.2 kN punching capacity: 220 Max speed XxY m / min. : 90/60 St tool magazine positions: 18 kW Electrical connection: 380V Pneumatic connection Nm3 / h: 8 positioning accuracy + /-mm: 0.1 mm Length: 14500 mm Width: 6100 mm Height: 2470 Weight kg: 13700 Standard equipment: Stable C framework that coordinates management with integrated linear magazine, 21 places for tools and clamps, 3 clamps, Automatic parts chute 500x500mm; Gutteilebehälter Drives: Maintenance-free AC servo motors; Punching head: Hydraulic single tool adapter, 360 rotation for all tools, automatic tool length compensation, Werkzeugsprühschmierung second Lubricant reservoir, programmable Abstreiferbewegung, Stanzbutzenabsaugung, programmable hold-down for repositioning with adjustable hold-down force, Aufwölbungserkennung, 3.5 "floppy drive RJ 45 network connection Safety: CE mark, multibeam photoelectric sensors, emergency shutdown equipment; features: multi-tool control, thread forms, sign / Fast crimping; Multishear; Softpunch 3 pieces separately openable clamps, height-adjustable Spanpratzen, Nachsetzzylinder, slide sensor for parts, automatic cut, chip conveyor with Tilting, scratch-free machining, Blow-out hardware, [...Technical data truncated]
Specifications:
-
