Job Title: 2535x1280 control: Siemens SINUMERIK 840 D mm Maximum thickness: 8 Max Werstückgewicht kg: 200 Max cutting diameter mm: 76.2 kN punching capacity: 220 Maximum travel speed XxY m / min. : 90/60 tool magazine slots pc: kW 18 Electrical connection: 380V pneumatic connection Nm3 / h: 8 Positioning accuracy + /-mm: 0.1 Length: 5700 Width mm 4100 Height mm: 2470 Weight kg: 13700 3 clamps, auto parts slide 500x500mm, and parts box punching head: Hydraulic single tool adapter, 360 rotation of all tools, automatic tool length compensation Werkzeugsprühschmierung; 2.Schmiermittelbehälter; programmable Abstreiferbewegung; Stanzbutzenabsaugung; chip pot programmable down device for repositioning with selectable hold-down power programmable logic controller, diagnostics, graphics programming ToPs 2000, 3.5 " Floppy disk drive connector BNC and RJ45 network, multi-beam light barriers, hydraulic scram, multi-tool control, tapping, vibration dampers;

-
