Description:
Job Title: 3085x1650 control: Siemens SINUMERIK 840 D mm Maximum thickness: 8 Max Werstückgewicht kg: 200 mm Max cutting diameter: 76.2 kN punching capacity: 220 Max speed XxY m / min. : 90/60 St tool magazine positions: 18 kW Electrical connection: 380V Pneumatic connection Nm3 / h: 8 positioning accuracy + /-mm: 0.1 mm Length: 7900 mm Width: 6300 mm Height: 2200 Weight kg: 21000 Standard equipment: Stable C framework, coordinate management with integrated linear magazine, 25 places for tools and clamps, 4 Spanpratzen, Automatic parts chute 500 x 500 mm, Gutteilebehälter, Drives: Maintenance-free AC servo motors; punching head: Hydraulic single tool adapter, 360 rotation f. all tools, automatic tool length compensation, Werkzeugsprühschmierung , 2 lubricant reservoir, programmable Abstreiferbewegung, Stanzbutzenabsaugung, chip bucket, programmable hold-down with the repositioning pre-selectable down force, Aufwölbungerkennung, control: SINUMERIK 840D TFT color screen 10.4 ", easy operation, diagnostics, graphics programming, ToPs 2000, Built-3.5%-floppy drive , RJ45 network port, Safety: CE mark, multi-beam light barriers, scram hydraulics, FMC preparation FEATURES: Multi-tool, multi Hear, tapping, slotting, marking / Fast beading, Nachsetzzylinder, sensor for parts chute, automatic shutdown, Au [...Technical data truncated]
Specifications:
-
