Manufacturer BRONX Ltd.
Model PBR-4
Working range
Ø 10 – 43 mm. Yield strength: 80/90 Kg/mm2
Ø 10 – 45 mm. Yield strength: 70/80 Kg/mm2
Ø 10 – 47 mm. Yield strength: 60/70 Kg/mm2
Ø 10 – 50 mm. Yield strength: 50/60 Kg/mm2
Ø 10 – 53 mm. Yield strength: 40/50 Kg/mm2
Ø 10 – 57 mm. Yield strength: 30/40 Kg/mm2
Adjustment of the rollers 10 – 20°
Speed 35 mt./min.
Motor power 2 x 30 kW d.c.
Tension 380 V. 50 Hz.
Specifications:
COMPOSITION OF THE LINE
Feeding channel of the two rolls straightening machine
Feeding pinch-roll
Two rolls straightening machine
Exit channel
Hydraulic equipment
Electric cabinet
Spare parts
Manual and drawings available
Note. the machine is presently under reconditioning
