TOTAL SIZE OF MACHINE FOR DEPTH WIDTH HEIGHT FOR 2020 × 2050 × 2000
Total weight of the machine with installation and electrical 3210 kg
Race X Y Z mm 350 220 220
Race U V mm 350220
Taper angle / height 30/220
Measurement resolution X Y Z U V 0.5 mikron
Shifter linear scales
Travel speed of axes 900 mm minute
Impact protection for all axes
WORK AREA
Maximum size of the piece 1000 × 550 × 220 (width by depth by height)
Maximum weight of 750 kg Workpiece
Automatic level dielectric
WASHING
pressure levels programmable 4
Pressure injection nozzle upper and lower nozzle 2/4/8/13
ELECTRODE / WIRE
Standard 0.25 mm wire guides
automatic threading
Maximum height for automatic threading wire from 0.25 mm 220 mm

-
