5/8" STAR MODEL SR-16 CNC PRECISION SWISS TYPE BAR MACHINE
General Specifications
CNC control Fanuc 16TTA
Max. turning diameter 5/8"
Max. headstock strike 8"
Max. drilling cap.:
Stationary tool 5/16"
Power-driven attachment 3/16"
Spindle speed 500-10,000 RPM
Main spindle motor 2.2 Kw/3.7 Kw
Main spindle indexing 15 deg.
Power-driven att. spin. speed:
Cross mill 350-5000 RPM
Slotting 60-900 RPM
No. of tools 5-OD
Mill/Drill /slot (3-Cross, 3-ID end working & 3-ID Backworking)
Tool shank size 12.7mm x 95mm
Sub-spindle (back working):
Max. chucking dia. 5/8"
Max. length for fron ejection 3-5/32"
Spindle speed 400-6000 RPM Dimensions (approx) 7'x3.5'x6.5'H Weight (approx) 3600 Lbs
Motor Specifications
Not Available
Equipped With
Fanuc 16TT CNC controls
3 Live tool stations
Parts Catcher & Parts conveyor
Coolant system & Splash guards
Iemca mini boss 325/37 magazine bar feed,s/n 97031707
Serial Number
G30657 Year
1995 Location
PROSPECT HEIGHTS, IL
Specifications:
5/8" STAR MODEL SR-16 CNC PRECISION SWISS TYPE BAR MACHINE
General Specifications
CNC control Fanuc 16TTA
Max. turning diameter 5/8"
Max. headstock strike 8"
Max. drilling cap.:
Stationary tool 5/16"
Power-driven attachment 3/16"
Spindle speed 500-10,000 RPM
Main spindle motor 2.2 Kw/3.7 Kw
Main spindle indexing 15 deg.
Power-driven att. spin. speed:
Cross mill 350-5000 RPM
Slotting 60-900 RPM
No. of tools 5-OD
Mill/Drill /slot (3-Cross, 3-ID end working & 3-ID Backworking)
Tool shank size 12.7mm x 95mm
Sub-spindle (back working):
Max. chucking dia. 5/8"
Max. length for fron ejection 3-5/32"
Spindle speed 400-6000 RPM Dimensions (approx) 7'x3.5'x6.5'H Weight (approx) 3600 Lbs
Motor Specifications
Not Available
Equipped With
Fanuc 16TT CNC controls
3 Live tool stations
Parts Catcher & Parts conveyor
Coolant system & Splash guards
Iemca mini boss 325/37 magazine bar feed,s/n 97031707
Serial Number
G30657 Year
1995 Location
PROSPECT HEIGHTS, IL
